Exploring Remote Zoo Models#
This section walks you through the process of using remotely-sourced models from the FiftyOne Model Zoo—models whose definitions are hosted on public GitHub repositories or accessible via external URLs.
With this approach, you can:
Seamlessly integrate custom models hosted on GitHub or cloud archives
Reproduce and share models across teams and projects using standardized links
Apply these models to your datasets within FiftyOne just like built-in zoo models
FiftyOne’s flexible zoo API supports both built-in and remote models. That means whether you’re pulling a model from voxel51/openai-clip, ultralytics/yolov5, or your own repository, the workflow remains consistent and intuitive.
In this notebook, you’ll learn how to:#
Specify remote model sources using GitHub repos, branches, or commit references
Load and apply these models to your datasets
Visualize the predictions directly in the FiftyOne App
[ ]:
!export GITHUB_TOKEN=<your_token_here>
💡 To use private GitHub repositories, be sure to set the
GITHUB_TOKENenvironment variable with your personal access token.
[ ]:
!pip install fiftyone torch torchvision
💡 Before starting, ensure you’ve installed the required packages:
Using Florence2 as Remotely Sourced Zoo Model#
Original documentation of this Remotely Sourced Zoo Model is here
[1]:
import fiftyone as fo
import fiftyone.zoo as foz
# Load a dataset
dataset = foz.load_zoo_dataset("quickstart", overwrite=True)
dataset=dataset.take(1)
Overwriting existing directory '/home/harpreet/fiftyone/quickstart'
Downloading dataset to '/home/harpreet/fiftyone/quickstart'
Downloading dataset...
100% |████| 187.5Mb/187.5Mb [468.8ms elapsed, 0s remaining, 400.1Mb/s]
Extracting dataset...
Parsing dataset metadata
Found 200 samples
Dataset info written to '/home/harpreet/fiftyone/quickstart/info.json'
Loading existing dataset 'quickstart'. To reload from disk, either delete the existing dataset or provide a custom `dataset_name` to use
For context, here is the first image:
[2]:
from PIL import Image
Image.open(dataset.first().filepath)
[2]:
Setup Zoo Model#
[ ]:
foz.register_zoo_model_source("https://github.com/harpreetsahota204/florence2", overwrite=True)
[ ]:
foz.download_zoo_model(
"https://github.com/harpreetsahota204/florence2",
model_name="microsoft/Florence-2-base-ft",
)
[ ]:
model = foz.load_zoo_model(
"microsoft/Florence-2-base-ft"
)
The three captioning operations require no additional arguments beyond selecting the operation type.
Supported detail_level values:
basicdetailedmore_detailed
[4]:
model.operation="caption"
model.detail_level= "basic"
[5]:
dataset.apply_model(model, label_field="captions")
100% |█████████████████████| 1/1 [750.4ms elapsed, 0s remaining, 1.3 samples/s]
[6]:
dataset.first()['captions']
[6]:
'A birthday cake decorated with surfboards and palm trees.'
To change the caption detail level:
[7]:
model.detail_level= "more_detailed"
dataset.apply_model(model, label_field="more_detailed_captions")
dataset.first()['more_detailed_captions']
100% |█████████████████████| 1/1 [222.7ms elapsed, 0s remaining, 4.5 samples/s]
[7]:
'A birthday cake is sitting on a table. The cake is blue. There are two palm trees on top of the cake. There is a white banner on the cake with writing on it.'
The operations for detection, dense_region_caption, region_proposal don’t require additional parameters for general use.
However, open_vocabulary_detection requires a text_prompt parameter to guide the detection towards specific objects.
The results are stored as Detections objects containing bounding boxes and labels:
[10]:
model.operation="detection"
model.detection_type="open_vocabulary_detection"
model.prompt="a surfboard next to palm trees"
dataset.apply_model(model, label_field="ov_prompted_detection")
100% |█████████████████████| 1/1 [108.8ms elapsed, 0s remaining, 9.2 samples/s]
[11]:
dataset.first()['ov_prompted_detection']
[11]:
<Detections: {
'detections': [
<Detection: {
'id': '67ed9dcce1d525ba81848cc8',
'attributes': {},
'tags': [],
'label': 'a surfboard next to palm trees',
'bounding_box': [
0.28949998361995805,
0.2964999914169312,
0.30999999609999,
0.16000001430511473,
],
'mask': None,
'mask_path': None,
'confidence': None,
'index': None,
}>,
],
}>
Or you can use the caption field:
[12]:
dataset.apply_model(model, label_field="ov_field_detection", prompt_field="captions")
100% |█████████████████████| 1/1 [125.0ms elapsed, 0s remaining, 8.0 samples/s]
[13]:
dataset.first()['ov_field_detection']
[13]:
<Detections: {
'detections': [
<Detection: {
'id': '67ed9dd6e1d525ba81848cc9',
'attributes': {},
'tags': [],
'label': 'A birthday cake decorated with surfboards and palm trees.',
'bounding_box': [
0.09549999541748827,
0.02449999898672104,
0.8030000022425058,
0.9640000239014626,
],
'mask': None,
'mask_path': None,
'confidence': None,
'index': None,
}>,
],
}>
For dense detections, this runs without a prompt and returns all detectable objects.
[14]:
model.operation="detection"
model.detection_type="dense_region_caption"
dataset.apply_model(model, label_field="dense_detections")
100% |█████████████████████| 1/1 [106.1ms elapsed, 0s remaining, 9.4 samples/s]
[15]:
dataset.first()['dense_detections']
[15]:
<Detections: {
'detections': [
<Detection: {
'id': '67ed9de2e1d525ba81848cca',
'attributes': {},
'tags': [],
'label': 'surfboard',
'bounding_box': [
0.2914999818649536,
0.3644999980926514,
0.2639999877149686,
0.09099998474121093,
],
'mask': None,
'mask_path': None,
'confidence': None,
'index': None,
}>,
<Detection: {
'id': '67ed9de2e1d525ba81848ccb',
'attributes': {},
'tags': [],
'label': 'surfboard',
'bounding_box': [
0.41449998361995805,
0.3014999866485596,
0.1830000222300569,
0.10799999237060547,
],
'mask': None,
'mask_path': None,
'confidence': None,
'index': None,
}>,
],
}>
Phrase grounding requires either a direct caption or a reference to a caption field. You can provide this in two ways:
[16]:
model.operation="phrase_grounding"
model.prompt="cake"
dataset.apply_model(model, label_field="cap_phrase_groundings")
100% |█████████████████████| 1/1 [84.9ms elapsed, 0s remaining, 11.8 samples/s]
[17]:
dataset.first()['cap_phrase_groundings']
[17]:
<Detections: {
'detections': [
<Detection: {
'id': '67ed9df1e1d525ba81848ccc',
'attributes': {},
'tags': [],
'label': 'cake',
'bounding_box': [
0.09249999804999501,
0.02449999898672104,
0.8099999473498652,
0.963000001013279,
],
'mask': None,
'mask_path': None,
'confidence': None,
'index': None,
}>,
],
}>
When you want to use a Field of a Sample for grounding, you use the following pattern:
[18]:
dataset.apply_model(model,
label_field="cap_field_phrase_groundings",
prompt_field="more_detailed_captions"
)
100% |█████████████████████| 1/1 [168.3ms elapsed, 0s remaining, 5.9 samples/s]
[19]:
dataset.first()['cap_field_phrase_groundings']
[19]:
<Detections: {
'detections': [
<Detection: {
'id': '67ed9dfde1d525ba81848ccd',
'attributes': {},
'tags': [],
'label': 'A birthday cake',
'bounding_box': [
0.08950000068250175,
0.02249999940395355,
0.8179999525173784,
0.9650000005960464,
],
'mask': None,
'mask_path': None,
'confidence': None,
'index': None,
}>,
<Detection: {
'id': '67ed9dfde1d525ba81848cce',
'attributes': {},
'tags': [],
'label': 'The cake',
'bounding_box': [
0.09349999717249276,
0.5134999752044678,
0.8070000231075591,
0.47300000190734864,
],
'mask': None,
'mask_path': None,
'confidence': None,
'index': None,
}>,
<Detection: {
'id': '67ed9dfde1d525ba81848ccf',
'attributes': {},
'tags': [],
'label': 'two palm trees',
'bounding_box': [
0.239500003120008,
0.02249999940395355,
0.5619999699699231,
0.3499999910593033,
],
'mask': None,
'mask_path': None,
'confidence': None,
'index': None,
}>,
<Detection: {
'id': '67ed9dfde1d525ba81848cd0',
'attributes': {},
'tags': [],
'label': 'a white banner',
'bounding_box': [
0.34649999453998603,
0.1434999942779541,
0.3389999828399561,
0.10999999046325684,
],
'mask': None,
'mask_path': None,
'confidence': None,
'index': None,
}>,
],
}>
Segmentation requires either a direct expression or a reference to a field containing expressions.
Similar to phrase grounding, you can provide this in two ways:
[ ]:
model.operation="segmentation"
model.prompt="palm trees"
dataset.apply_model(model, label_field="prompted_segmentations")
[ ]:
dataset.first()['prompted_segmentations']
When you want to use a Field of a Sample for grounding, you use the following pattern:
[22]:
dataset.apply_model(model, label_field="sample_field_segmentations", prompt_field="captions")
100% |█████████████████████| 1/1 [4.7s elapsed, 0s remaining, 0.2 samples/s]
[ ]:
dataset.first()['sample_field_segmentations']
Basic OCR (“ocr”) requires no additional parameters and returns text strings. For OCR with region information (ocr_with_region), you can set store_region_info=True to include bounding boxes for each text region:
[24]:
model.operation="ocr"
model.store_region_info=True
dataset.apply_model(model, label_field="text_regions")
100% |█████████████████████| 1/1 [220.6ms elapsed, 0s remaining, 4.5 samples/s]
[25]:
dataset.first()['text_regions']
[25]:
<Detections: {
'detections': [
<Detection: {
'id': '67ed9e2de1d525ba81848cd3',
'attributes': {},
'tags': [],
'label': '</s>Sweetness Bakery',
'bounding_box': [
0.03249999890312219,
0.032499998807907104,
0.3559999831568319,
0.03899999856948853,
],
'mask': None,
'mask_path': None,
'confidence': None,
'index': None,
}>,
<Detection: {
'id': '67ed9e2de1d525ba81848cd4',
'attributes': {},
'tags': [],
'label': 'HAPPY 30TH BIRTHDAY',
'bounding_box': [
0.38449998556996307,
0.17350000143051147,
0.2520000226200579,
0.049999988079071044,
],
'mask': None,
'mask_path': None,
'confidence': None,
'index': None,
}>,
],
}>
[26]:
model.store_region_info=False
dataset.apply_model(model, label_field="text_regions_no_region_info")
100% |█████████████████████| 1/1 [126.7ms elapsed, 0s remaining, 7.9 samples/s]
[27]:
dataset.first()['text_regions_no_region_info']
[27]:
'Sweetness BakeryHAPPY 30TH BIRTHDAY'
Remotely-sourced models expand the power and flexibility of the FiftyOne Model Zoo by allowing you to access and deploy models from external GitHub repositories or public URLs. Whether you’re leveraging a popular open-source model or integrating one from your own team, this workflow makes it easy to apply and visualize predictions in your datasets.
